Overview
ZLAN1043N is a powerful single-chip serial port to TCP/IP chip, which integrates 10/100M fast Ethernet MAC and PHY interfaces, UART serial ports, and software functions required for serial port to TCP/IP. Different from ordinary solutions, ZLAN1043N has three advantages: easy to use, stable and reliable, and low system cost. ZLAN1043N can be used to maximize the convenience of the design of TCP/IP and Internet interconnection products.
The convenience of ZLAN1043N is reflected in the fact that it is a real single-chip serial port to TCP/IP chip that can be used out-of-the-box, and UART to TCP/IP data transmission can be realized without any driver. After the chip is powered on, the user does not need to configure the parameters, because all the parameter configurations can be configured through the network port with ZLVircom software, and the user can configure all the internal parameters of the ZLAN1043N with one click through ZLVircom. As a TCP client, the ZLAN1043N automatically establishes a TCP connection, and as a TCP server, it automatically accepts the connection without any intervention from the user's MCU. All the user MCU needs to do is wait for the ZLAN1043N initialization to complete and then send and receive serial port (UART) data.
The stability of the ZLAN1043N is reflected in the fact that the internal TCP/IP protocol stack of the ZLAN1043N has been proven by years of commercial application practice. Internal includes: TCP, UDP, IPv4, IMP, ARP, HTTP, etc.
Peculiarity
- It supports Modbus gateway function and Modbus RTU to Modbus TCP. It can support storage-based Modbus, which can automatically collect and store device data, and also supports Modbus gateway in non-storage mode.
- Support multi-host function: In the one-question-and-answer query mode, the network port allows multiple computers to access the same serial port device at the same time.
- Support custom heartbeat package and registration package function: it can easily communicate with the cloud and identify devices.
- TCP connection requires password verification to ensure connection security.
- It supports the data submission and delivery function of http, and the cloud can directly use the http GET command to interact with the serial port data of the device.
- The level of 8 IO ports can be controlled through arbitrary network commands.
- The P2P network NAT traversal function is supported.
Web interface
- Ethernet
- 10/100 Mbps
Serial interface
- Interface
- 3.3V UART
- Number of serial ports
- 1
- Check digit
- None, Even, Odd, Space, Mark
- Data bits
- 5～9
- Stop bits
- 1,2
- Flow control
- RTS/CTS,DTR/DCR,XON/XOFF
- Speed
- 1200bps～460800bps
Software features
- Agreement
- TCP,HTTP,UDP,ICMP,ARP,IP,DNS,DHCP
- Virtual serial platform
- Windows 98/2000/XP/WIN7/WIN8
- Configuration
- Web browser, ZLVirCom, serial port AT commands
Electrical characteristics
- Voltage input
- Supply voltage: 3.3V, IO voltage: 5V, 230mA maximum current
Mechanical properties
- Size
- See data sheet
Working environment
- Operating temperature, humidity
- 0～70℃，5～95% RH
- Storage temperature, humidity
- -45～165℃，5～95% RH
